Connect 45° Angled Fuel Line Quick Connectors 7.89 x 3pc 6-8mm
Connect 45° Angled Fuel Line Quick Connectors 7.89 x 3pc 6-8mm
Connect 45° Angled Fuel Line Quick Connectors 7.89 x 3pc 6-8mm

Connect 45° Angled Fuel Line Quick Connectors 7.89 x 3pc 6-8mm

by Connect
SKU 34230-LAS
Sold out
£16.99 - £16.99
£16.99
£16.99 - £16.99
£16.99

Free Standard Delivery for Orders Over £40*

Length: 6

Product Information

A set of 3 angled fuel line quick connectors allowing for tight connections on 6mm fuel lines. The 45° angle provides easier fixing in tight spaces. Quick connectors are designed for the automotive industry for the transfer of fuel, oil, water cooling systems and air. The self locking connector enables it to be connected and disconnected with ease and speed, with the wide operating temperature range ensures it can cope with the extreme temperatures that could lead to cracking and leaks.

Features
  • 45° angled connectors, suits: 6mm ID nylon pipe; 7.5mm ID rubber hose.
  • Constant running pressure: 5 bar (72psi); max pressure: 7 bar (101psi). Operating temperature: -40°C to 120°C.
  • Body manufactured from nylon PA12; O-ring from FKM seal (Viton). Made to SAE J2044-220908 standards.
  • Grey tab for fuel identification (note: AdBlue® specific connectors have red tabs).
  • Included in assorted box of 45° angled quick fuel line connectors, see Connect Part No. 34229.

Available in 2 length options 6 and 8 — use the selector above to pick the exact one for the job.

Available lengths

Use the length selector at the top of this page to choose your option. Each option is dispatched as a separate stocked item.

Specifications
Length EAN
6 5018341342302
8 5018341342319
Brand Connect
EAN 5018341342302
Type Fuel Connectors
Sub-Type Fuel Related products
Item Weight 0.046 kg
Custom Bundle No
Item Width 97mm
Item Height 61mm
Item Depth 183mm
Country/Region of Manufacture China
Customs Tariff Number 39174000
Number in Set 3
Length 8mm
Application Automotive
Manufacturer Part Number (MPN) CPL
