Laser Tools Twin Function Brake Punch 4.8-5.5mm
Laser Tools Twin Function Brake Punch 4.8-5.5mm
Laser Tools Twin Function Brake Punch 4.8-5.5mm

Laser Tools Twin Function Brake Punch 4.8-5.5mm

by Laser Tools
SKU 7867-LAS
Sold out
£12.99 - £12.99
£12.99
£12.99 - £12.99
£12.99

Free Standard Delivery for Orders Over £40*

Length: 4.8

Product Information

A specially designed, 4.8mm pin punch particularly suited to use on vehicle brake pad pins where the pins are a tight fit and the ends of the pins at risk of spreading out (mushrooming) and jamming in the caliper which can happen when standard flat punches are used. This issue is often seen with Brembo type calipers. The punch is made up of 2 punches in one, the short punch has a specially machined, concaved end that ensures the initial force of impact is concentrated on the circumference of the pin to significantly reduce the chances of mushrooming. Once the pin has moved, the longer pin can be used to continue the removal process.

Features
  • Double punch to assist in the removal of stuck brake pins.
  • Size: 4.8mm x 135 / 65mm.
  • Concaved ended short pin combined with full length extraction pin.
  • Manufactured from chrome vanadium & plated for corrosion resistance.
  • Punches are considered consumable; 3 pin set available – please see Laser Part No. 7865. Other sizes available - please see Laser Part Nos. 7866 (3mm), 7868 (5.5mm). EU Registered Design.

Available in 2 length options 4.8 and 5.5 — use the selector above to pick the exact one for the job.

Available lengths

Use the length selector at the top of this page to choose your option. Each option is dispatched as a separate stocked item.

Specifications
Length EAN
4.8 5018341078676
5.5 5018341078683
Brand Laser Tools
EAN 5018341078676
Type Brake Disc & Pad Tools
Item Weight 0.07 kg
Custom Bundle No
Item Width 60mm
Item Height 11mm
Item Depth 130mm
Country/Region of Manufacture Taiwan Province of China
Customs Tariff Number 82034000
Sub-Type BRAK
Length 5.5mm
Application Automotive
Manufacturer Part Number (MPN) PL
